性能 Capability

主要技術參數

Main technical parameter

流量 Flow

10-20m/h

總揚程 Total distance

18-20m

其中吸程

5-6m

葉輪輪輻直徑 impeller diameter

Φ189mm

進出口管徑 Entrance & Exit diameter

Φ51mm

電動機型號Electromtor type

Y112-4

功率power

4KW（380V.50HZ)

轉速Rotanting speed

1420r/min

外形尺寸（長×寬×高） Size (L×W×H）

600×350×420

機器重量Weight

55kg

型號Type

流量（噸/小時）Flow(ton/h)

揚程（米水柱）Distance (Mwater column)

電機功率electricpower

進出口徑entrance&exit diameter

TLW-1.5-14

1.5

14

0.5

40/25

32/25

TLW-3-14

2

14

1.1

40/32

38/38

TLW-5-24

5

24

1.5

50/40

51/38

TLW-5-32

5

32

2.2

50/40

51/38

TLW-10-24

10

24

2.2

50/40

51/38

TLW-10-36

10

36

3

50/40

51/38

TLW-15-24

15

24

3

50

51

TLW-20-24

20

24

4

50

51

TLW-20-36

20

36

5.5

50

51

TLW-25-24

25

24

4

50/50

51/51

TLW-30-24

30

24

5.5

65/50

63/51

TLW-30-36

30

36

7.5

65/50

63/51

TLW-30-60

30

60

11

65/50

63/51

TLW-35-36

35

36

11

65/50

76/63

TLW-40-36

40

36

11

80/65

76/63

TLW-40-45

40

45

11

80/65

101.6/76

TLW-50-36

50

36

11

80/65

101.6/76

TLW-80-30

80

30

15

100/85

TLW-80-40

80

40

18.5

100/85

TLW-100T-40

100

40

22

125/100

TLW-100T-70

100

70

33

125/100

型號Type

建議選用流量范圍(t/h)

功率（KW）

揚程

進口口徑

出口

口徑

TLCLP1-100(B)

0.5-1.5

0.37

8-4

25

25

TLCLP1-120(B)

0.5-1.5

0.55

15-10

25

25

TLCLP3-110(B)

2-4

0.55

11-7

38

25

TLCLP3-120(B)

2-4

0.75

15-9

38

25

TLCLP3-140(B)

2-5

1.1

24-12

38

25

TLCLP5-140(B)

4-8

1.1

22-12

50.8

32

TLCLP5-150(B)

4-8

1.5

27-19

50.8

32

TLCLP5-165(B)

4-8

2.2

33-27

50.8

32

TLCLP5-180(B)

4-8

3

42-35

50.8

32

TLCLP10-150(B)

7-14

2.2

24-13

50.8

38

TLCLP10-165(B)

7-14

3

32-23

50.8

38

TLCLP10-175(B)

7-14

4

37-31

50.8

38

TLCLP10-182(B)

7-14

4

42-37

50.8

38

TLCLP20-165(B)

16-25

4

29-21

50.8

50.8

TLCLP20-180(B)

16-25

5.5

36-28

50.8

50.8

TLCLP20-192(B)

16-25

7.5

44-36

50.8

50.8

TLCLP20-210(B)

16-25

7.5

52-46

50.8

50.8

TLCLP30-165(B)

22-40

5.5

29-18

63.5

50.8

TLCLP30-180(B)

22-40

7.5

38-28

63.5

50.8

TLCLP30-192(B)

22-40

7.5

45-36

63.5

50.8

TLCLP30-210(B)

22-40

11

51-45

63.5

50.8

TLCLP50-165(B)

42-60

7.5

29-21

76

63.5

TLCLP50-180(B)

42-60

11

37-29

76

63.5

TLCLP50-192(B)

42-60

11

43-36

76

63.5

TLCLP50-210(B)

42-60

15

51-46

76

63.5
